Klüberlub BE 71-501 is a light-coloured special lubricating grease for highly loaded rolling and plain bearings. It offers good compatibility with nonferrous metals, such as those used as plain bearing materials. Due to its special formulation and solid lubricants, wear is low under rotating and oscillating motion and high impact loads. It is resistant to water and has a good sealing effect. The additives contained in this product enhance its ageing resistance.
Benefits for Your Application
-
Versatile lubricant for highly loaded rolling and plain bearings.
-
Reduced operating and maintenance costs due to low consumption.
-
Good wear protection when exposed to high loads.
-
Long grease life due to low operating temperatures and friction.
-
Low waste water disposal costs and long service life of components due to good water resistance.
Product Data
| Item |
Value |
| Product |
Klüberlub BE 71-501 |
| Chemical composition, solid lubricant |
Contains solid lubricant |
| Chemical composition, thickener |
Polyurea |
| Chemical composition, type of oil |
Mineral oil |
| Colour |
Yellow |
| Lower service temperature |
-20 °C / -4 °F |
| Service temperature, upper limiting value for continuous lubrication |
160 °C |
| Service temperature, rolling bearings, acc. to DIN 51825 |
140 °C |
| Worked penetration, DIN ISO 2137, 25 °C, lower limit |
310 x 0.1 mm |
| Worked penetration, DIN ISO 2137, 25 °C, upper limit |
340 x 0.1 mm |
| Kinematic viscosity of the base oil, DIN 51562 pt. 01/ASTM D-445/ASTM D 7042, 40 °C |
approx. 490 mm²/s |
| Kinematic viscosity of the base oil, DIN 51562 pt. 01/ASTM D-445/ASTM D 7042, 100 °C |
approx. 32 mm²/s |
| Lubricating greases -K, DIN 51825 in connection with DIN 51502 |
KPF1N-20*; Emcor max. 2 |
| Speed factor (n x dm) |
approx. 300 000 mm/min |
| Corrosion inhibiting properties, DIN 51802 (SKF-EMCOR), test duration: 1 week, distilled water |
≤ 2 corrosion degree |
| Copper corrosion, DIN 51811, 24h/100°C |
1 - 100 corrosion degree |
| Drop point, DIN ISO 2176 |
≥ 200 °C |
| Flow pressure of lubricating greases, DIN 51805, test temperature: -20 °C |
≤ 1 400 mbar |
| Four-ball tester, welding load, DIN 51350 pt. 04 |
≥ 4 000 N |
| Four-ball EP tester, wear value, DIN 51350 part 5, procedure E, 60s/1000N, wear scar diameter |
≤ 1 mm |
| Load-carrying capacity acc. to Brugger, based on DIN 51347-1 and -2 |
≥ 30 N/mm² |
| Water resistance, DIN 51807 pt. 01, 3 h/90 °C, rating |
≤ 1 - 90 |
| Minimum shelf life from date of manufacture, in a dry, frost-free place and in the unopened original container |
approx. 24 months |
Application
Klüberlub BE 71-501 can contribute to extending the service life of plain bearings where low-wear and low-friction operation is required under mixed friction conditions. This special grease meets the requirements in terms of reduced lubricant consumption and extended lubrication intervals in forging presses while maintaining a constant temperature level in the plain bearing. It can also be used for plain bearings subject to high loads in the plastics processing industry and building machines (e.g. ring-roll mills) and in construction machines. Owing to the good results achieved on rolling bearing test rigs and the good pumpability of the grease in commercial central lubrication systems, Klüberlub BE 71-501 is also suitable for high-temperature applications, especially in the steel industry (e.g. ring-roller mills) and woodworking industry (e.g. rolling bearings in pelleting presses).
Application Notes
Klüberlub BE 71-501 can be applied by means of central lubrication systems or by brush, spatula, grease gun and automatic metering devices. When switching to Klüberlub BE 71-501, the lubricant consumption should be reduced step by step in order to ensure that used lubricant, wear particles and impurities are completely removed from the bearing.
FAQ
Q1:
What types of bearings is Klüberlub BE 71-501 suitable for?
A1:
It is suitable for highly loaded rolling bearings and plain bearings.
Q2:
Is the product compatible with nonferrous metals?
A2:
Yes. It offers good compatibility with nonferrous metals, such as those used as plain bearing materials.
Q3:
What is the upper service temperature limit?
A3:
The upper limiting value for continuous lubrication is 160 °C; for rolling bearings according to DIN 51825, it is 140 °C.
Q4:
What is the lower service temperature?
A4:
The lower service temperature is -20 °C / -4 °F.
Q5:
Is the product water-resistant?
A5:
Yes. It is resistant to water and has a good sealing effect. Its water resistance according to DIN 51807 pt. 01, 3 h/90 °C, is rated ≤ 1 - 90.
Q6:
Can it be used in central lubrication systems?
A6:
Yes. It can be applied by means of central lubrication systems and has good pumpability in commercial central lubrication systems.
Q7:
What should be noted when switching from another grease?
A7:
When switching to Klüberlub BE 71-501, the lubricant consumption should be reduced step by step to ensure that used lubricant, wear particles and impurities are completely removed from the bearing.
Q8:
What is the shelf life?
A8:
The minimum shelf life from the date of manufacture is approx. 24 months in a dry, frost-free place and in the unopened original container.
Q9:
What are the main application industries?
A9:
They include forging presses, plastics processing industry, building machines, construction machines, steel industry (e.g. ring-roller mills) and woodworking industry (e.g. rolling bearings in pelleting presses).
Q10:
How can I obtain the material safety data sheet?
A10:
It can be requested via www.klueber.com or through your contact person at Klüber Lubrication.
