LOCTITE® 406 Instant Adhesive Enables High Precision and Rapid Production in Electronic Sensor Assembly

Challenge: An automotive electronic sensor manufacturer faced challenges during the assembly of a new oxygen sensor. The sensor housing, made of transparent polycarbonate, required a strong bond with an interface component made of ABS plastic. The challenges were:

• High Precision Requirements: The bond line needed to be extremely thin and uniform to ensure sensor airtightness and avoid stress on internal components.
• Production Efficiency: Traditional bonding methods had long curing times, creating a production bottleneck.
• Material Compatibility: The adhesive had to exhibit excellent adhesion to both polycarbonate and ABS without causing stress cracking or unsightly "blooming," which could affect sensor appearance and performance.

Solution: After evaluation, the manufacturer selected Henkel's LOCTITE® 406 instant adhesive. The product's characteristics perfectly matched the application requirements:

• Very Fast Cure Speed: On polycarbonate and ABS materials, at 22°C/50% RH, the fixture time (to achieve 0.1 N/mm² strength) is between less than 5 seconds and 20 seconds, significantly improving production cycle time.
• Low Viscosity and High Penetrability: With a viscosity range of 12-25 mPa·s, it easily fills minute capillary gaps, creating a uniform and high-strength thin bond line.
• Excellent Material Compatibility: Technical data shows a lap shear strength of 9.1 N/mm² (~1,320 psi) on polycarbonate and 8.8 N/mm² (~1,280 psi) on ABS, ensuring structural reliability.
• Transparent and Colorless: It remains transparent after curing, preserving the aesthetic appeal of the sensor housing.

Implementation Process:

• Surface Preparation: Bonding surfaces of the polycarbonate housing and ABS component were thoroughly cleaned and degreased using a LOCTITE® cleaning solvent.
• Precision Dispensing: Automated dispensing equipment was used to precisely control the amount and location of adhesive application, ensuring a thin, uniform bond line.
• Rapid Assembly: Components were pressed together within seconds after dispensing, utilizing the fast fixturing property of LOCTITE® 406 for immediate holding.
• Strength Development: The assemblies reached full strength (with complete chemical resistance) after 24 hours before proceeding to the next testing stage.

Results Achieved:

• 30% Increase in Production Efficiency: Rapid fixture time reduced the assembly waiting period per unit.
• Product Yield Exceeded 99.5%: Uniform bond strength and excellent airtightness ensured consistent high reliability of the sensors.
• Resistance to End-Use Environment: The cured LOCTITE® 406 demonstrated good resistance to motor oil, gasoline/ethanol blends, etc. (according to TDS data, strength retention typically above 85%-100% after testing), meeting the demanding requirements of the automotive engine compartment environment.

Conclusion: LOCTITE® 406, with its very fast curing speed, excellent bond strength on various plastics and elastomers, and ease of use, proves to be an ideal choice for bonding precision electronic components, medical devices, and small plastic parts requiring rapid assembly. This case study demonstrates its strong capability in solving efficiency and reliability challenges within demanding automotive electronics manufacturing.
